C. DIFFERENCES BETWEEN THE PMC-SC

AND THE PMC-N, AND HOW TO

MIGRATE FROM THE PMC-N/NA TO

THE PMC-SC/SC3/SC4/NB/NB2

B–61863E–1/06

APPENDIX

482

To activate a task under the same condition as that with the PMC-N/NA,

the procedure shown below must be followed.

(1) Activation at power-on: Activate a task with a high task level.

Activation

[Outline flowchart]

RETURN

Processing

(2) Cycle activation : Create a task using the os_show_tim and

os_sync_tim commands of the PMC system call

library.

Activation

[Outline flowchart]

Initialization of local variables

Processing

Timer waiting

* The user task is responsible for determining whether to execute

tasks from the beginning.

C.2

TASK ACTIVATION

CONDITIONS
