10. C-LANGUAGE LIBRARY
B–61863E–1/06
APPLICATION
PROGRAMMING GUIDE
446
10
C-LANGUAGE LIBRARY
The PMC C language libraries are distributed with floppy disks for the
types of PMC as follows:
PMC–SC C language library : A08B–9201–J701
PMC–NB C language library : A08B–9201–J703
Copy the original floppy disk onto the system’s hard disk or another
floppy disk and store the original.
When using the FANUC standard library in Section 3.2, substitute
include file STDIO.H with STDLIB.H provided by Intel.
The mathematic functions, use the PMC–RC C language library
“PMC3.LIB” provided by FANUC and substitute include file
“math.h”,“reent.h” provided by Intel.
[Disk contents]
INC . . . . . .
TOOL
SAMPLE . .
PMCLIB.H (include file for the PMC library)
PMCFLT.H (include file for the FANUC standard library)
STDLIB.H (include file for the FANUC standard library)
STDIO.H (include file for the FANUC standard library)
MATH.H (include file for the FANUC standard library)
REENT.H (include file for the FANUC standard library)
PMC.LIB (PMC library)
PMC2.LIB (FANUC standart library)
PMC3.LIB (FANUC mathematic function library)
PMCFLT.LIB (FANUC floating–point operation library)
Sample program source files, command files, and execution load modules
PCAT MKC.EXE (tool for creating link control statement data on a PC/AT). . . . . . .
PC98 MKC.EXE (tool for creating link control statement data on a PC9801). . . . . . .
HEX2MEM HEX2MEM.EXE (tool for converting Hex file to Mem file). . .
DIC_DATA.TXT (C language title file)
LIB . . . . . .
* See Chapter 11 for details of the sample program.
