PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 593

Programming manual

Page of 619

/ 619

FANUC PMC C language function

Supplemental Programming Manual

01 01.05.29

Maruyama

New registration

B-61863E-1/06-1

EDIT DATE DESIG.

DESCRIPTION

12/23

TITLE

DRAW.NO.

Table 9.5.3 Relationship between displayed soft-keys and setting parameters

Soft-key Parameter

[TITLE]

[USRDGN]

Always Displayed

[TITLE]->[SYSPRM]

[CLEAR]

[DEBUG]

1.”EDIT ENABLE” to “YES” (K901.6 to 1) and

“ALLOW PMC STOP” to “YES” (K902.2 to 1)

2.”PROGRAMMER ENABLE” to “YES” (K900.1

to 1)

[TITLE]->[EDIT]

[GDT]

[USRMEM]

1.”EDIT ENABLE” to “YES” (K901.6 to 1)

2.”PROGRAMMER ENABLE” to ”YES” (K900.1

to 1)

[GDT]->[M.DUMP]->[INPUT]

[USRMEM]->[TASK.D]->[M.DUMP]->[INPUT]

[USRMEM]->[TASK.S]->[M.DUMP]->[INPUT]

[USRMEM]->[COM.D]->[M.DUMP]->[INPUT]

1.”EDIT ENABLE” to “YES” (K901.6 to 1) and

“RAM WRITE ENABLE” to “YES” (K900.4 to

2.”PROGRAMMER ENABLE” to “YES” (K900.1

to 1) and “RAM WRITE ENABLE” to “YES”

(K900.4 to 1)

Warning

When the machine is shipped into the field, please set the parameter

“PROGRAMMER ENABLE” to “NO” (or set bit 1 of the keep relay K900 to 0) not to

display the soft-keys

[ GDT ]

[USRMEM]

[DEBUG ]

and

[CLEAR ].
