PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 444

Programming manual

Page of 619

/ 619

9. C-PROGRAM MEMORY DISPLAY

AND DEBUG FUNCTION

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

428

PMC USER MEMORY(TASK DATA) MONIT RUN

ID NAME GDT BASE LIMIT

10 TASK-O01 039 00160050H 00010100H

11 TASK-O02 040 00160060H 00004100H

12 TASK-O03 041 00160070H 00005100H

13 TASK-O04 042 00160080H 00000160H

14 TASK-O05 043 00160210H 00000170H

15 TASK-O06 044 00160110H 00000110H

[ TASK.D ][ TASK.S ][ COM.D ][ M.DUMP ][ ]

Fig.9.2.1 (a) Display of Data in the Task Data Area

PMC USER MEMORY(TASK STACK) MONIT RUN

ID NAME GDT BASE LIMIT

10 TASK-O01 239 00161050H 00010100H

11 TASK-O02 240 00161060H 00004100H

12 TASK-O03 241 00161070H 00005100H

13 TASK-O04 242 00161080H 00000160H

14 TASK-O05 243 00161210H 00000170H

15 TASK-O06 244 00161110H 00000110H

[ TASK.D ][ TASK.S ][ COM.D ][ M.DUMP ][ ]

Fig.9.2.1 (b) Display of Data in the Task Stack Area

PMC USER MEMORY(COMMON DATA) MONIT RUN

NO GDT BASE LIMIT

01 042 00162010H 00000100H

02 045 00162020H 000A0100H

03 047 00162030H 0000D000H

04 048 00162040H 0000A100H

[ TASK.D ][ TASK.S ][ COM.D ][ M.DUMP ][ ]

Fig.9.2.1 (c) Display of Data in the Common Memory Data Area
