PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 547

Programming manual

Page of 619

/ 619

B–61863E–1/06

G. HINT FOR MAKING LINK CONTROL

STATEMENT, COMMAND FILE

FOR BINDER, BUILD FILE

APPENDIX

531

D USER GDT ADDRESS (Link control statement)

D RANGE (Build file)

a. Setting of the start address of C application code

Specify in Link control statement and Build file.

1) Link control statement

Set at the main screen of MKC(Link control statement creation

tool)

USER GDT ADDRESS = 845000

2) Build file

RANGE = (

TASK_CODE = ROM(000845000H

..0008FFFFFH),

TASK_DATA = RAM(000000000H..0000FFFFFH)

)

On SYSPRM screen, under the line of ’LANGUAGE ORIGIN’,

’LANGUAGE AREA = xxxxxxxx, SIZE = yyyKB’ is shown.

Set the value within the range from ’xxxxxxx’ to ’xxxxxxxx+yyy’.

CAUTION

Set the same value to Link control statement, Build file.

(the part of under line which is shown above)

b. Setting of the end address of the C application code

Specify in the Build file.

RANGE = (

TASK_CODE = ROM(000845000H..0008FFFFFH

TASK_DATA = RAM(000000000H..0000FFFFFH)

)

Set end address within the range to the value ’LANGUAGE

ORIGIN’+’SIZE’.

CAUTION

If ’LADDER MAX SIZE’ is modified on SYSPRM screen,

’LANGUAGE AREA’ and ’SIZE’ is changed.

Modify the ’LADDER MAX SIZE’ to near size of LADDER

program (shown on TITLE screen on PMCDGN) to get

larger C language area.

c. Setting of the address of C application data

Specify in the Build file.

RANGE = (

TASK_CODE = ROM(000845000H..0008FFFFFH),

TASK_DATA = RAM(000000000H

..0000FFFFFH)

)

Specify 0H to start address and FFFFFH to the end address,

because PMC system locates the data segment of each task.

G.2

SETTING OF THE

ADDRESS OF THE C

APPLICATION
