PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 153

Programming manual

Page of 619

/ 619

B–61863E–1/06

1. GENERALPMC LIBRARY

137

System information reading functions

No. Function name Description RC/RC3/RC4 NB/NB2 16i/18i/21i 15i-A

6.1 pl_sysinfrd Reads the system information. f f f f

6.2 pl_symcmt Reads symbol and comment data of the lad-

der program.

f f f

6.3 pl_message Reads message data of the ladder program. f f f

f: Supported, : Not supported

Functions for accessing expanded nonvolatile memory

No. Function name Description RC/RC3/RC4 NB/NB2 16i/18i/21i 15i-A

7.1 pl_kpmrd Reads data from expanded nonvolatile

memory.

f f f f

7.2 pl_kpmwrt Writes data into expanded nonvolatile

memory.

f f f f

7.3 pl_kpmsiz Reads the maximum size of expanded non-

volatile memory.

f f f f

f: Supported, : Not supported

CRT character display functions

No. Function name Description RC/RC3/RC4 NB/NB2 16i/18i/21i 15i-A

8.1 pl_dspclr Clears the entire screen of the CRT character

display.

f f f f

8.2 pl_dspclrl Clears lines on the CRT character display. f f f f

8.3 pl_dspclrc Clears an area on the CRT character display

specified in units of columns.

f f f f

8.4 pl_dsppos Specifies a position on the CRT character

display.

f f f f

8.5 pl_dspcolor Specifies the color of characters on the CRT

character display.

f f f f

8.6 pl_dspattr Changes the attributes of characters on the

CRT character display.

f f

8.7 pl_dspstr Displays alphanumeric and other characters

on the CRT screen.

f f f f

8.8 pl_dspstrw Displays Kanji, Hiragana and other special

characters on the CRT screen.

f f f f

8.9 pl_dsptrblr Displays characters tripled in size on the

CRT screen.

f f f f

8.10 pl_cursor Displays the cursor on the CRT screen. f ∆ f f

8.11 pl_dspopen Initializes the 14” CRT screen (character dis-

play) having 25 rows 80 columns.

f f

8.12 pl_dspopen2 Initializes the 14” CRT screen (character dis-

play) having 27 rows 74 columns.

f f

8.13 pl_dspopen3 Initializes the 14” CRT screen (character dis-

play) having 27 rows 80 columns.

f f f

8.14 pl_dspchar Displays the character string with the speci-

fied display position and display attribute.

f f f f

8.15 pl_dspsave Saves the CRT display characters. f f

8.16 pl_dspresave Restores the CRT display characters. f f

8.17 pl_dspcntl Instructs CRT display control. f f

8.18 pl_dspopen4 Initializes the 30–by–80 VGA display screen

(character display).

f f f

8.19 pl_backcolor Specifies the background color for the text

display.

f f
