PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 467

Programming manual

Page of 619

/ 619

B–61863E–1/06

11. SAMPLE PROGRAM

APPLICATION

PROGRAMMING GUIDE

451

USER;

SEGMENT

SEG_MDI_CODE (DPL=3 ), -- PCMDI SIGNAL TASK

SEG_MDI_DATA (DPL=3 ),

SEG_DEMO_CODE (DPL=3 ), -- CRT DISPLAY TASK

SEG_DEMO_DATA (DPL=3 ),

SEG_PMCLIB_CODE (DPL=3 ) -- PMC LIB CODE

;

TABLE GDT (

RESERVE = (3H..1FH), -- USED BY PMC-RC SOFTWARE

-- USER ENTRY = (20H..5FH)

entry= (

20H:SEG_MDI_CODE, -- PCMDI SIGNAL TASK

21H:SEG_MDI_DATA,

22H:SEG_DEMO_CODE, -- CRT DISPLAY TASK

23H:SEG_DEMO_DATA,

24H:SEG_PMCLIB_CODE -- PMC LIB CODE

)

);

TASK DUMMY_TASK (

CODE = pcload

);

MEMORY

(

RANGE = (

TEST_CODE = ROM(000845000H..0008FFFFFH),/*RC/RC3/RC4*/

/* = ROM(000245000H..0002FFFFFH),NB */

/* = ROM(000900200H..0009FFFFFH),16i/18i */

TEST_DATA = RAM(000000000H..0000FFFFFH)

ALLOCATE=(

TEST_CODE = (

GDT ,

IDT ,

SEG_MDI_CODE , -- PCMDI SIGNAL TASK CODE

SEG_DEMO_CODE , -- CRT DISPLAY TASK CODE

SEG_PMCLIB_CODE -- PMC LIB CODE

TEST_DATA = (

SEG_MDI_DATA , -- PCMDI SIGNAL TASK DATA

SEG_DEMO_DATA -- CRT DISPLAY TASK DATA

)

) -- end configuration section --

);

end

11.4

CONTENTS OF THE

BUILD FILE
