B–61863E–1/06

4. CREATION OF LINK

CONTROL STATEMENT

APPLICATION

PROGRAMMING GUIDE

407

(1) Data input

Data are input by entering the setting values and pressing the Return

key. However, if a setting value is input and the Cursor Shift key is

pressed, the setting value is invalidated.

(2) Page shifting

In order to shift pages:

For the PC98 ; Pressing the ROLL UP key displays the next page

and pressing the ROLL DOWN key displays the

previous page.

For the IBM-PC ; Pressing the PgUp key displays the next page and

pressing the PgDw key displays the previous

page.

(3) Cursor shift processing

The cursor can be shifted: Upwards with the ↑ key.

Downwards with the ↓ key.

To the left with the ← key.

To the right with the → key.

(4) Screen switching

A screen can be switched: To the main screen for creation of the

Link Control Statement with the MAIN

(F1) key.

To the common memory definition

screen with the MEMORY (F2) key.

To the task information definition screen

with the TASK (F3) key.

(5) Aborting processing

If the user does not wish to change the contents of the opened file,

processing can be aborted by pressing the QUIT (F9) key. It can also

be aborted after the EXIT (F10) key is pressed.

(6) Specification of the name of the file to be output

When setting is completed, an output file can be created by pressing

the EXIT (F10) key.

[When the file name is not changed]

Press the Return key.

[When the file name is to be changed]

Enter a new file name and press the Return key.

(7) Deletion of one character

When a character is to be deleted, the cursor (blinking cursor) should

be moved to the character to be deleted and then the DEL key should

be pressed. The character before the selected character can be deleted

with the BS (backspace) key.

CAUTION

If either of the following is executed, start the Link Control

Statement creation tool again.

a) A file has been created while the floppy disk is in

write-protect status.

b) The STOP key (PC-98) is pressed while the Link Control

Statement creation tool is being activated.

4.2

KEY OPERATION OF

THE LINK CONTROL

STATEMENT

CREATION TOOL
