10. READER/PUNCHER INTERFACE

B–61863E–1/06

PMC LIBRARY

272

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f f

[Name]

pl_fopen2

[Description]

Opens the file according to the control method and conditions of the

specified channel and makes the file usable, when the FANUC

cassette is used as an input/output device.

[Format]

ret = pl_fopen2(p, file_no, file_name) ;

short ret ;

short *p ;

short file_no ;

char *file_name ;

[Input]

*p RS_232C information

OD OS

IC OC

file_no : Specify the file number with which data is read or the file

is created.

For file name specification, specify “file_no” = 0.

file_name: Specify the file name with which data is read or the file

is created, using the ASCII code. Up to 17 characters can

be used for the file name.

Suffix NULL to the character string.

For file number specification, specify “file_name” = 0.

CAUTION

If both the file number and file name are specified, the file

name takes precedence over the file number.

(a) Specifying the channel and control method (OP)

(n represents a channel number(Note) ).

OP = 1n : Data is input using channel n (DC1/DC3 automatic

control)

D When the file is opened, the DC1 control code which

requests sending

data is automatically send to the

destination device. When the interface is closed, the DC3

control code is sent. When an overflow of the receiving

buffer is detected, output is automatically controlled by

DC1 or DC3 code(when data is input from the FANUC

cassette).

2n : Data is output using channel n (DC2/DC4 automatic

control)

D When the file is opened, the DC2 control code which

requests receiving

data is automatically send to the

destination device. When the interface is closed, the DC4

control code is sent. Data transmission is suspended or

restarted automatically from the remote device using DC3

and DC1 (when data is output to the FANUC cassette).

10.12

OPENING THE

READER/PUNCHER

INTERFACE (FOR

THE FANUC FLOPPY

CASSETTE)

OP Specifying the channel and control method to be used (a). . . .

OB Specifying the baud rate (b). . . .

OS Specifying the stop and parity bits (c). . . .

OD Specifying the DC3 code (d). . . .

OC Specifying the code for data output (e). . . .

IC Specifying the code for data input (f). . . . .
