PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 429

Programming manual

Page of 619

/ 619

B–61863E–1/06

5. BUILD FILE CREATION

APPLICATION

PROGRAMMING GUIDE

413

Build file (Example)

Below is an example that uses two tasks and common memory.

-- SMPL.bld

USER; -- build program id

SEGMENT

TASK1_CODE (DPL=3 ), -- TASK 1

TASK1_DATA (DPL=3 ),

TASK2_CODE (DPL=3 ), -- TASK 2

TASK2_DATA (DPL=3 ),

COM_DATA (DPL=3 ), -- COMMON DATA

SEG_PMCLIB_CODE (DPL=3 ) -- PMC LIB CODE

;

TABLE GDT (

RESERVE = (3H..1FH),-- USED BY PMC-RC SOFTWARE

-- GDT(0) is All zeros (null

descriptor)

-- GDT(1) is Alias Segment for IDT

-- GDT(2) is Alias Segment for GDT

-- GDT(3H)-GDT(1FH) is Used by pmc-rc software

USER ENTRY = (20H..5FH)

entry= (

20H:TASK1_CODE, -- TASK 1

21H:TASK1_DATA,

22H:TASK2_CODE, -- TASK 2

23H:TASK2_DATA,

24H:COM_DATA, -- COMMON DATA

25H:SEG_PMCLIB_CODE -- PMC LIB CODE

)

);

TASK DUMMY_TASK (

CODE = smpl_tsk1

);

MEMORY

(

RANGE = (

TASK_CODE = ROM(000845000H..0008FFFFFH),

TASK_DATA = RAM(000000000H..0000FFFFFH)

ALLOCATE=(

TASK_CODE = (

GDT,

IDT,

TASK1_CODE, -- TEST TASK 1 CODE

TASK2_CODE, -- TEST TASK 2 CODE

SEG_PMCLIB_CODE -- PMC LIB CODE

TASK_DATA = (

TASK1_DATA, -- TEST TASK 1 DATA

TASK2_DATA, -- TEST TASK 2 DATA

COM_DATA -- COMMON DATA

)

) -- end configuration section --

);

end
