B–61863E–1/06

D. EXAMPLES OF PROGRAMSAPPENDIX

491

D When X1000.0 is off, K10.0 is turned on and off every 80 ms

(timer-wait).

D When X1000.0 is on, K10.1 is turned on and off every 160 ms (loop).

/*==============================================================*/

/* time man */

/*==============================================================*/

#include <pmclib.h>

#define K10_0 27264+(10*8)+0

#define K10_1 27264+(10*8)+1

#define X1000_0 12800+0

unsigned long tim ;

void far smpl_tim()

{

unsigned long new_tim ;

unsigned long old_tim ;

for( ; ; )

{

os_show_tim( &tim ) ;

for( ; !pl_membrd( X1000_0 ) ; )

{

tim += 10 ;

os_sync_tim( tim ) ; /* 80ms wait */

pl_membwrt(K10_0,(pl_membrd(K10_0))?0:1); /* K10.0 == ON/OFF */

}

for( ; pl_membrd( X1000_0 ) ; )

{

new_tim = 0 ;

os_set_tim( new_tim, &old_tim ) ;

do{

os_show_tim(&tim) ;

}while( tim < 20 ) ; /* 160ms loop */

pl_membwrt(K10_1,(pl_membrd(K10_1))?0:1); /* K10.1 == ON/OFF */

}

D.1

TIMER

MANAGEMENT

FUNCTION
