6. EXECUTION FILE CREATION

APPLICATION

PROGRAMMING GUIDE

415

(2) Binding each task

Binding is performed several times for each task. Because all

functions in the C286 standard library are near-type, it must be bound

to each task.

[Bind format]

BND386 &<TASK1.CON

TASK1.CON : Bind control file

[Contents]

CTL.OBJ,&

TASK1.OBJ,&

CLIB2C.LIB &

OJ (TASK1.LNK) NOLO NOPL EC (smpl_tsk1) &

PR (TASK1.MP1) NAME (TASK1) SS (STACK(0)) &

RN(CODE TO TASK1_CODE,DATA TO TASK1_DATA)

CTL.OBJ,TASK1.OBJ: Compile object file

CLIB2C.LIB : C286 standard library

OBJECT(OJ) : Specifies the bind output file name.

NOLOAD(NOLO) : Outputs files which can be rebound.

NOPUBLICS(NOPL) : Prevents other tasks and symbols from

conflicting.

EXCEPT(EC) : Only outputs symbols of the task entry

functions.

PRINT(PR) : Specifies the name of the output listing file

for bind results.

NAME(NA) : Module name

SEGSIZE(SS) : Sets the stack size to 0.

RENAMESEG(RN) : Specifies a unique segment name for each

task. Make sure to change data segment

names.

When the FANUC library (PMC2.LIB PMC3.LIB library functions

in 3.2) is used with the standard C library, bind PMC2.LIB

PMC3.LIB before binding CLIB2C.LIB.

TCB.OBJ,&

TASK1.OBJ,&

PMC2.LIB, &

PMC3.LIB, &

CLIB2C.LIB, &

OJ(TASK1.LNK) NOLO NOPL EC(smpl_tsk1) &

PR(TASK1.MP1) NAME(TASK1) SS(STACK(0)) &

RN(CODE TO TASK1_CODE,DATA TO TASK1_DATA)

(3) Common memory is bound as shown below.

[Bind format]

BND386 &<COMDAT.CON

COMDAT.CON: Bind control file

[Contents]

COMDAT.OBJ &

OJ(COMDAT.LNK) NOLO PL &

PR(COMDAT.MP1) NAME(COMDAT) &

RN(DATA TO COM_DATA)

PUBLICS(PL) : Outputs symbols.
