B-65395EN/01 HANDLING 3.PERIPHERAL EQUIPMENT CONTROL

- 117 -

CAUTION

This improvement is intended for ATC/turret control,

and is not applied to point positioning with function

code 3. Response data is also output if point

positioning is performed, but it does not contain the

point number but the turret/magazine number based

on the current position. Also, the MINP, +MOR, and

-MOR signals are not those corresponding to the

point number but corresponding to the

turret/magazine number. Also note that the response

data output if another function code is issued contains

the turret/magazine number and the MINP, +MOR,

and -MOR signals based on the current position.

NOTE

1 Information is not updated real-time and, therefore,

the function cannot be used for such purposes as the

position switch, which must monitor the position

constantly. (Response data based on the position at

the time when the logic of ABSWT (X

x+1

#0) is inverted

is retained, and is not updated the next time the logic

of ABSWT is inverted.)

2 When reading response data using ABSWT (X

X+1

#0)

and ABSRD (Y

y+1

#4), note that there are variations of

up to 40 ms in the transfer between the host and the

servo amplifier module. If, therefore, response data

is read during axis movement, the response data may

not match the current turret/magazine number and

the MINP, +MOR, and -MOR signals because of the

variations. The variation maximum may be greater

depending on how the ladder program is created.

3 Even if, after the power is turned on, response data is

read using ABSWT (X

X+1

#0) an ABSRD (Y

y+1

#4)

before performing ATC/turret control, the

turret/magazine number and the MINP, +MOR, -MOR

signals based on the current position are output.

4 If the current position is near a magazine number

boundary, the turret/magazine number may fluctuate

if the motor fluctuates.

5 For compatibility with conventional types, bit 5

(ATCR2) of parameter No. 007 must be set to "1" to

use this improved type.

6 No response data is output until the reference

position is established. If bit 2 (NZRPO) of parameter

No. 007 is set to "1", however, response data is

output even if the reference position is not

established.
