B-65395EN/01 APPENDIX B.PARAMETER LIST

- 285 -

180 Reference counter capacity

[Size] 4-byte

[Valid data range] 1 to 99999999

[Standard value] 10000

This parameter specifies a reference counter capacity.

Reference counter capacity = number of pulses per motor revolution

(detection increment)

181 Grid shift amount

[Size] 4-byte

[Valid data range] 0 to ±99999999

[Standard value] 0

A grid position can be shifted by the amount specified in this parameter

so that the reference position can be shifted. The unit of shift is a

detection increment. The maximum grid shift amount that can be

specified is half or less than the reference counter capacity.

182 Positional deviation limit value during movement

[Size] 4-byte

[Valid data range] 0 to 99999999

[Standard value] 3333

This parameter specifies a positional deviation limit value used when

the motor is rotating. Alarm No. 411 is raised, if this value is exceeded,

leading to deceleration and stop.
