4.DIRECT COMMANDS HANDLING B-65395EN/01

- 142 -

(5) Reading the acceleration/deceleration delay

The host can read the acceleration/deceleration delay in the servo

amplifier module.

● Instruction command format

#7 #6 #5 #4 #3 #2 #1 #0

Yy+4 Control flag 1

Yy+5 0 0 1 1 0 1 0 0 (0x34)

Yy+6 0 0 0 0 0 0 0 1

● Response command format

#7 #6 #5 #4 #3 #2 #1 #0

Xx+4 Control flag 2

Xx+5 0 0 1 1 0 1 0 0 (0x34)

Xx+6 Reserved Execution result

Xx+7

Xx+8

Xx+9

Xx+10

Acceleration/deceleration delay data (DWORD type)

(6) Reading the actual feedrate

The host can read the actual feedrate of the servo amplifier

module.

● Instruction command format

#7 #6 #5 #4 #3 #2 #1 #0

Yy+4 Control flag 1

Yy+5 0 0 1 1 0 1 1 0 (0x36)

● Response command format

#7 #6 #5 #4 #3 #2 #1 #0

Xx+4 Control flag 2

Xx+5 0 0 1 1 0 1 1 0 (0x36)

Xx+6 Reserved Execution result

Xx+7

Xx+8

Xx+9

Xx+10

Actual feedrate data (DWORD type)
