B-65395EN/01 HANDLING 2.SIGNAL DESCRIPTIONS

- 41 -

Servo amplifier module → CNC (host) (DRC=1)

7 6 5 4 3 2 1 0

Xx+0 INPX SUPX IPLX DEN2

Xx+1 OP SA STL OPTENB ZRFX DRCO WAT

Xx+2 MA AL TRQM RST ZPX

Xx+3 INPFO SVERX PSG2 PSG1 MVX APBAL MVDX

Xx+4 EBSY EOSTB ECF USR1 EOPC DAL ECONT

Xx+5 Direct command (function code)

Xx+6 Reserved Execution result

Xx+7 Direct command (response data 1)

Xx+8 Direct command (response data 2)

Xx+9 Direct command (response data 3)

Xx+10 Direct command (response data 4)

Xx+11 Direct command (response data 5)

Xx+12 Direct command (response data 6)

Xx+13 Direct command (response data 7)

Xx+14 Direct command (response data 8)

Xx+15 Direct command (response data 9)

See Section 2.3 for details of the signals. Section 4.4 explains the

function number, command data, and response data.
