(2) Detailed information of Axis and Coordinate
Axis and Coordinate Detailed Information
ID No.
Meaning
100
101
102
No. of CNC controlled axes
No. of PMC controlled axes
No. of axes
110
111
112
113
114
115
116
117
1st axis relative coordinate value
2nd axis relative coordinate value
3rd axis relative coordinate value
4th axis relative coordinate value
5th axis relative coordinate value
6th axis relative coordinate value
7th axis relative coordinate value
8th axis relative coordinate value
(3) Miscellaneous information including the total number of machined
parts
The information of ID Nos. 210, 220, 222, 224, and 226 is given in
minutes.
Example: When ID No. 220 indicates 360, this information means
6 hours.
When ID No. 220 indicates 369, this information means
6 hours and 9 minutes.
When ID No. 224 indicates 359, this information means
5 hours and 59 minutes.
The information of ID Nos. 221, 223, 225, and 227 is given in 1/1000
seconds.
Example: When ID No. 221 indicates 3000, this information
means 3 seconds.
When ID No. 221 indicates 36000, this information
means 36 seconds.
No. of Total Parts Machined, etc.
ID No.
Meaning
200
201
202
Total number of Parts machined
Number of parts required
Number of parts machined
210 Power on time
220
221
222
223
224
225
226
227
Operation time
Operation time
Cutting time
Cutting time
General purpose integrated time
General purpose integrated time
Cycle time
Cycle time
(4) Automatic screen clear state (i Series)
The information with ID No. 320 indicates whether the NC screen has
been placed in the clear or display state by the automatic screen clear
function.
Previous page
Next page
