1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 415

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
405
D Drilling (T one-spindle type) <Ver.3>
[Drilling]
C–axis Drilling PROC(01) AREA MACHIN-2 PATTERN PROC-DIA TOOL-NO T-CODE
0 214411418
REV/MIN FEED/MIN DWELL CUT-DPTH INTERVAL
15 16 40 30 9
[Reaming]
C–axis Drilling PROC(01) AREA MACHIN-2 PATTERN PROC-DIA CHAMFLNG
0 2144178
TOOL-NO REV/MIN FEED/MIN DWELL INTERVAL T-CODE
14 15 16 40 9 18
[End milling]
C–axis Drilling PROC(01) AREA MACHIN-2 PATTERN PROC-DIA TOOL-NO T-CODE
0 214411418
REV/MIN FEED/MIN DWELL INTERVAL
15 16 40 9
[Boring]
C–axis Drilling PROC(01) AREA MACHIN-2 PROC-DIA TOOL-NO REV/MIN T-CODE
0 214141518
FEED/MIN DWELL SHIFT INTERVAL
16 40 42 9
D C-axis tapping (TT, T two-spindle type)
C-axis tapping PROC(01) AREA HEAD NOMINL-D PITCH TOOL-D REV/MIN T-CODE
0 2 3 39 43 14 15 18
FEED/MIN DWELL INTRVAL
16 40 9
D C-axis tapping (T one-spindle type)
C-axis tapping PROC(01) AREA NOMINL-D PITCH TOOL-D REV/MIN T-CODE
0 2 3943141518
FEED/MIN DWELL INTRVAL
16 40 9
D C-axis grooving (TT, T two-spindle type)
[Spindle positioning type : Only standard grooving on the side face enabled]
C-axis grooving PROC(01) HEAD GRV-DIA TOOL-NO REV/MIN FEEDRATE1 T-CODE
(rough) 0 3 4814154918
FEEDRATE2 BEVEL-AM
51 53
C-axis grooving PROC(01) HEAD GRV-DIA TOOL-NO REV/MIN FEED/MIN T-CODE
(chamfer) 0 3 4814151618
BEVEL-AM
53
[Contour control type - machining area: End face]
C-axis grooving PROC(01) AREA HEAD GRV-DIA TOOL-NO REV/MIN FEEDRATE1 T-CODE
(rough) 0 2 3 48 14 15 49 18
FEEDRATE2 SHAPE BEVEL-AM
51 10 53
C-axis grooving PROC(01) AREA HEAD GRV-DIA TOOL-NO REV/MIN FEED/MIN T-CODE
(chamfer) 0 2 3 48 14 15 16 18
SHAPE BEVEL-AM
10 53
* For the T two-spindle type, UNIT is replaced with SPINDLE.
