SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 443

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
433
(21)Start point for drawing the profile of the tailstock
Command format G10 P90101 X_Z_ ;
Specifies the start point for drawing the profile of the tailstock.
X : X coordinate of the start point for drawing the profile of the
tailstock in the current workpiece coordinate system
Z : Z coordinate of the start point for drawing the profile of the
tailstock in the current workpiece coordinate system
(22)Start point for drawing the profile of a blank
Command format G10 P90102 X_Z_ ;
Specifies the start point for drawing the profile of a blank.
X : X coordinate of the start point for drawing the profile of a
blank in the current workpiece coordinate system
Z : Z coordinate of the start point for drawing the profile of a
blank in the current workpiece coordinate system
(23)Drawing the end-face view used for C-axis machining
Command format G10 P90103 ;
Draws the end-face view used for C-axis machining.
(24)Drawing the exploded view used for C-axis machining
Command format G10 P90104 ;
Draws the exploded view used for C-axis machining.
(25)Copying the profile of a workpiece
Command format G10 P90200 X_Z_I_K_ ;
Copies the profile of a workpiece drawn in the specified area from the
first graphic screen to the second graphic screen or vice versa.
X : X coordinate of the upper right point of the area to be copied
Z : Z coordinate of the upper right point of the area to be copied
I : X coordinate of the lower left point of the area to be copied
K : Z coordinate of the lower left point of the area to be copied
NOTE
The command copies the profile of a workpiece to the
screen on which the command is issued. When the
command is specified in head 2, for example, the profile is
copied from head 1 to head 2. The coordinates must be
those on the source screen. When the profile is copied from
head 1 to head 2, for example, the coordinates must be
those in the workpiece coordinate system of head 1. The
coordinates cannot be omitted.
This command is effective only for a lathe with two spindles
and two turrets.
(26)Coordinate conversion to those in the copy destination
Command format G10 P90201 X_Z_ ;
X, Z : Differences between coordinates used in two heads with
reference to those in the source area
