6. FUNCTIONS OF THE MACRO
EXECUTOR
B–61803E–1/10
PROGRAMMING
54
Table 6 (b) Functions of the Macro Executor and the Associated G Codes and Macro Variables (2/2)
No. Function
Associated G
code
Associated macro vari-
able
Conversa-
tional
Auxiliary
Executa-
ble
6.23 Interlock along each axis  #8600, #8601 Ę
(NOTE 5)
Ę
(NOTE 5)
6.24 Separation of P-CODE pro-
gram UI/UO
  Ę Ę Ę
6.25 Referencing the common
variables for custom macros
 #99000 Ę Ę Ę
6.26 Displaying the conversational
macro screen when power is
turned on
  Ę
6.27 Masking screen switching
with the CUSTOM key
  Ę
6.28 Searching for a P-CODE
workpiece number
  Ę
6.29 Function for calling a user pro-
gram with an executable mac-
ro
  Ę
6.30 Arithmetic function   Ę Ę Ę
(NOTE 6)
6.31 MDI key image read function
by conversational macro
 #8549 Ę
6.32 Window function  #8998, #8999 Ę Ę
6.33 Special character registera-
tion and display function
  Ę
(NOTE 7)
6.34 Execution macro call mask
function
 #8690, #8691 Ę Ę Ę
Ę : Usable ∆ : Partially usable : Unusable
NOTE
1
Since the Series 21-TB (control unit A) do not support the graphic
display feature, they cannot use the drawing, painting, or other
functions based on the graphic coordinate system.
2 This function can be used only for Series 16-A/18-A/20/21-TA/
21-TB (control unit A)/21-MB (D201 series).
3 This function can not be used for Series 20 and for Series 21.
4 This function can not be used for Series 20-TA.
5 This function can not be used for Series 20.
6 To use the arithmetic function in the execution macro, custom
macro B option must be combined in the CNC.
7 This function can be used only for Series 20.
