SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 484

Programming manual
J. PARAMETERS
B–61803E–1/10
APPENDIX
474
#7 #6 #5 #4 #3 #2 #1 #0
9004 CUTLG NOP_B HRGC IMG SP_G_C SP_G_B
SP_G_B, SP_G_C
00:Standard G code system
01:G code system B
10:G code system C
11:G code system C
IMG 0 : FS16-T type (Special G code)
1 : FS16-G type (Special G code)
NOP_B 0 : When no other address is specified in a block that calls a
subprogram by a T or M code, the block is executed.
The vacant block is executed with a T code macro call or
a macro call with an axis address.
1 : The block is not executed.
The vacant block is not executed with a T code macro call
or a macro call with an axis address.
HRGC 0 : 9” high resolusion monochrome CRT, standard
1 : 9” high resolution monochrome CRT, brightness
modulation mode setting (paint)
CUTLG 0 : Does not count cutting distance
1 : Count cutting distance
#7 #6 #5 #4 #3 #2 #1 #0
9005 TMACC AXCLS AX4CL AX3CL AX2CL AX1CL
AX1CL 0 : Macro program call by the 1st address is invalid
1 : Macro program call by the 1st address is valid
AX2CL 0 : Macro program call by the 2nd address is invalid
1 : Macro program call by the 2nd address is valid
AX3CL 0 : Macro program call by the 3rd address is invalid
1 : Macro program call by the 3rd address is valid
AX4CL 0 : Macro program call by the 4th address is invalid
1 : Macro program call by the 4th address is valid
AXCLS 0 : Always program O9009 is called irrespective of specified
axes.
1 : The program number to be called depends on a specified
axis:
Program O9031 is called when 1st axis is specified.
Program O9032 is called when 2nd axis is specified.
::
Program O9038 is called when 8th axis is specified.
TMACC 0 : Macro call by T code is invalid
1 : Macro call by T code is valid
#7 #6 #5 #4 #3 #2 #1 #0
9006 US19W CNCHG DAUXR STDM KEYC DIOC
DIOC 0 : Standard UI:G54/G55 and UO:F54/F55 are used for
UI/UO(#1000-#1132) of execution macro/ conversational
macro.
1 : UI:G82/G83 and UO:F84/F85 are used for UI/UO
(#1000-#1132) of execution macro/ conversational macro.
