E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
407
[Machining area: Side face]
C-axis notching PROC(01) AREA HEAD STAT-PZ END-PTZ REMOVALX TOOL-NO T-CODE
(rough) 0 2 3 54 55 25 14 18
REV/MIN FEED/MIN FINISHX FINISHZ
15 16 56 57
C-axis notching PROC(01) AREA HEAD STAT-PZ END-PTZ TOOL-NO REV/MIN T-CODE
(finish) 0 2 3 54 55 14 15 18
FEED/MIN
16
D C-axis notching (T one-spindle type)
[Machining area: End face]
C-axis notching PROC(01) AREA STAT-PZ END-PTZ REMOVALX TOOL-NO T-CODE
(rough) 0 2 5455251418
REV/MIN FEED/MIN FINISHX FINISHZ
15 16 56 57
C-axis notching PROC(01) AREA STAT-PZ END-PTZ TOOL-NO REV/MIN T-CODE
(finish) 0 2 5455141518
FEED/MIN BEVEL-AM
16 53
C-axis notching PROC(01) AREA STAT-PZ TOOL-NO REV/MIN FEED/MIN T-CODE
(chamfer) 0 2 5414151618
BEVEL-AM
53
[Machining area: Side face]
C-axis notching PROC(01) AREA STAT-PZ END-PTZ REMOVALX TOOL-NO T-CODE
(rough) 0 2 5455251418
REV/MIN FEED/MIN FINISHX FINISHZ
15 16 56 57
C-axis notching PROC(01) AREA STAT-PZ END-PTZ TOOL-NO REV/MIN T-CODE
(finish) 0 2 5455141518
FEED/MIN
16
D C-axis cylindrical machining (TT, T two-spindle type)
C-axis cylindrical PROC(01) HEAD STAT-PX DEPTH GRV-DIA TOOL-NO T-CODE
machining (rough) 0 3 5859481418
REV/MIN FEEDRATE1 FEEDRATE2 BEVEL-AM
15 50 52 53
C-axis cylindrical PROC(01) HEAD STAT-PX DEPTH GRV-DIA TOOL-NO T-CODE
machining 0 3 5859481418
(chamfer) REV/MIN FEED/MIN BEVEL-AM
15 16 53
D C-axis cylindrical machining (T one-spindle type)
C-axis cylindrical PROC(01) STAT-PX DEPTH GRV-DIA TOOL-NO T-CODE
machining (rough) 0 58 59 48 14 18
REV/MIN FEEDRATE1 FEEDRATE2 BEVEL-AM
15 50 52 53
C-axis cylindrical PROC(01) STAT-PX DEPTH GRV-DIA TOOL-NO T-CODE
machining 0 58 59 48 14 18
(chamfer) REV/MIN FEED/MIN BEVEL-AM
15 16 53
* For the T two-spindle type, UNIT is replaced with SPINDLE.
