1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 514

Programming manual
N. DISPLAY WITH A BACKGROUND COLOR
ON THE CUSTOM SCREEN
B–61803E–1/10
APPENDIX
504
D Default values of CNC system
<Character palette>
Palette
No
R
value
G
value
B
value
Color Use in the CNC software
0 0 0 0 No color
1 8 0 0 Dark red Alarm
2 0 8 0 Dark green Title, soft key 1
3 8 8 0 Ocher Input keys, O/N number, status
display
4 15 15 0 Yellow Cursor
5 15 0 15 Purplish red Resume sequence, absolute
command
6 0 8 8 Pale
turquoise
Subtitle, soft key 2
7 3 1 1 Dull black Data, clock
8 0 0 0 Black (Used on the graphic screen)
9 15 0 0 Red (Used on the graphic screen)
10 0 15 0 Green (Used on the graphic screen)
11 15 15 0 Yellow (Used on the graphic screen)
12 0 0 15 Blue (Used on the graphic screen)
13 15 0 15 Purplish red (Used on the graphic screen)
14 0 15 15 Turquoise (Used on the graphic screen)
15 15 15 15 White (Used on the graphic screen)
<Graphic palette>
Palette
No
R
value
G
value
B
value
Color Use in the CNC software
0 0 0 0 Black (Used on the graphic screen)
1 15 0 0 Red (Used on the graphic screen)
2 0 15 0 Green (Used on the graphic screen)
3 15 15 0 Yellow (Used on the graphic screen)
4 0 0 15 Blue (Used on the graphic screen)
5 15 0 15 Purplish red (Used on the graphic screen)
6 0 15 15 Turquoise (Used on the graphic screen)
7 15 15 15 White (Used on the graphic screen)
8 0 0 15 Blue Active window bar
9 0 11 11 Pale
turquoise
Inactive window bar
10 15 15 15 White Title bar, key input line
11 11 9 9 Dark gray Window background
12 15 15 15 White Reverse video
13 12 11 11 Gray Background of data that can be
input
14 4 4 4 Dull black Shadow
15 12 11 11 Gray Background
