E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
446
Example: [Standard character in extended character palette 12] +
[extended palette 15 for the background]
*ABC* = *647*
(Data format) = 100000:
The data item represents a surface speed or rotational speed, and its
display and data input are handled in the same way as other processes.
(Data format) = 100001:
The data item represents coolant ON or OFF (1 = ON, 2 = OFF). The
data item is displayed as a string. Data can be entered using the soft
keys and numeric keypad.
(Data format) = 200000:
The data item is displayed as a string. Data can be entered using the
soft keys and numeric keypad.
(Data format) = 300001:
The data item represents a tool ID number. Data can be entered using
the soft keys and numeric keypad.
(Data format) = 300002:
The data item represents a T code. Data can be entered using the soft
keys and numeric keypad.
(1) System variables for multi–window display specification
#9111 = X coordinate of the upper–left point of the multi–window
#9112 = Y coordinate of the upper–left point of the multi–window
#9113 = Number of characters in the X direction (horizontal
direction of the screen) of the multi–window
#9114 = Number of characters in the Y direction (vertical direction
of the screen) of the multi–window
#9115 = Type of frame of the multi–window
0: Thin line, 1: Heavy line, 2: Three–dimensional window
#9116 = Color of the frame of the multi–window (color of the title bar
when the multi–window is a three–dimensional window)
0: Black, 1: Red, 2: Green, 3: Yellow, 4: Blue, 5: Purple,
6: Light blue, 7: White, 8 to 15: Extended colors
#9120 = Request for display to the system
– When 1 is entered, the system opens a window based on
the information of #9111 through #9116. When 2 is
entered, the system closes the window. Upon the
completion of processing, the system initializes #9120 to
0. Set 99 to return from the detail screen to the process
screen. Then, the system displays the process screen.
E.12.2
Software Package
Related to the Interface
Between the System
and User Programs
E.12.2.1
Interface Between the
Conversational Program
Screen and User
Programs
Previous page
Next page
