SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 590

Programming manual
B–61803E–1/10
APPENDIX
Q. FS16i/18i/21i–TA Super CAPi T Concerning
CAP Control Module and User’s Module
580
FS16/18–TB and FS16/18–TC adopts the method of loading it to the
custom memory of CNC that the MEM format file of Super CAP T/II T
combining the original part supplied from FANUC with the custom part
created by the machine tool builder.
The other way, FS16i/18i/21i–TA adopts the method of loading each
separately and of maintaining each independently.
The custom part is be able to separated into two parts, as the part as to
conversational function and the others.
That is to say, it is possible to separate into three modules in all.
Q.1
OUTLINE
