A. MACRO PROGRAM EXAMPLE
B–61803E–1/10
APPENDIX
226
(4) VDPLX O9504
1. Function
To display a continuous variable value, this function deviates it
in the X-direction from the specified place on the CRT screen.
(Within one line)
2. Calling format
#140=F (F)
#141=Z (Z)
#142=X Display position on CRT
#143=Y
#144=V Variable No.(head)
#145=N No. of display
#146=E End code
#147=nX Deviation in the X-direction on the CRT
M98 P9504
E : END code
The display ends when the data which coincides with the end
code is reached even within the number of displays.
3. Remark
After this routine is executed, #140 - #147 values are saved.
(5) VDPLY O9505
1. Function
To display a continuous variable value, this function deviates it
in the Y-direction from the specified place on the CRT screen.
(within one column)
2. Calling format
#140=F
#141=Z
#142=X Display position on CRT
#143=Y
#144=V Variables No. (head)
#145=N No. of displays
#146=E End code
#147=nY Deviation in Y-direction on the CRT
M98 P9505
E : End code
The display ends when the data which coincides with the end
code is reached even within the number of displays.
3. Remark
After this routine is executed, #140 - #147 values are saved.
(6) DSPC O9506
1. Function
This function clears the screen, including the soft key.
2. Calling format
M98 P9506
