APPENDIX
280
If ID numbers are set in system variables #9990 and #9991, the cutting
condition data can be read into #9992 to #9996, depending on the values
set.
For example, in case (1) (a) shown below, if 18 is set in #9990 and 1 is
set in #9991, the feed amount, cutting speed, and cutting depth for
roughing material 1 with a general-purpose carbide tool are set in system
variables #9992, #9993, and #9994.
NOTE
1 Variables #9990 to #9996 are not used to read the chuck/tailstock
figure data. (See (10).)
2 This function is supported by versions 2 and 3 only.
(1) Cutting condition data screen for general-purpose tools
(a) Carbide tool
101 #L OUTER T0101 RN 0. 400 AC 95 AN 80 TW 20. 000
102 #R OUTER T0202 RN 0. 400 AC 95 AN 55 TW 20. 000
103 #L OUTER T0303 RN 0. 400 AC 95 AN 55 TW 20. 000
251 #L OUTER TH T0404 RN 0. 400 AN 60 TW 20. 000
252 #R OUTER TH T0505 RN 0. 400 AN 60 TW 20. 000)
*** MACHINING CONDITION (GENERAL) ***
[#9990=x] ROUGHING [#9990=y] FINISHING
CARBITE CARBITE
MATERIAL FEED/REV. CUT SPD. CUT DPTH MATERIAL FEED/REV. CUT SPD.
(MM/REV.) (M/MIN.) (MM) (MM/REV.) (M/MIN.)
<#9991=1> #9992 #9993 #9994 <#9991=1> #9992 #9993
<#9991=2> #9992 #9993 #9994 <#9991=2> #9992 #9993
<#9991=3> #9992 #9993 #9994 <#9991=3> #9992 #9993
<#9991=4> #9992 #9993 #9994 <#9991=4> #9992 #9993
<#9991=5> #9992 #9993 #9994 <#9991=5> #9992 #9993
<#9991=6> #9992 #9993 #9994 <#9991=6> #9992 #9993
<#9991=7> #9992 #9993 #9994 <#9991=7> #9992 #9993
<#9991=8> #9992 #9993 #9994 <#9991=8> #9992 #9993
SET FEEDRATE AMOUNT BY MAX. VALUE.
WORK
MATERL
MENU
RETRN
D Workpiece material 1 to 8 : x= 18, y= 19
D Workpiece material 9 to 16 : x=155, y=156
D Workpiece material 17 to 24 : x=161, y=162
NOTE
Workpiece materials 9 to 16 and 17 to 24 are available only when
99 tools can be registered.
E.6.1.3
Details of the Software
Package Associated with
the Cutting Condition
Data
