B–61803E–1/10
APPENDIXO. FANUC Super CAPi T
566
(*32) Spindle type
When complex lathe application is available:
1 : Spindle 1 2 : Spindle 2 5 : Both spindles
(*33) Specification of corner part of trapezoid groove pattern input
1 : Chamfer 2 : Corner R
(*34) Figure pattern for Trapezoid groove pattern input
0(or #0) : 6 points input 1 : Regular trapezoid groove
2 : Left taper groove 3 : Right taper groove
(*35) Process type
0(or #0) : Transfer process 1 : Wait process
(*36) Data about the automatic necking figure data calculation by the theread data
When the automatic necking figure data calculation by the theread data is available, this
data is available.
(*37) Thread number per 1 inch
When thread type is Unified, PT, or PF, this data is available.
(*38) When the processing area is a side, the data of the development chart of C axis milling
becomes effective.
