SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 159

Programming manual
B–61803E–1/10
6. FUNCTIONS OF THE MACRO
EXECUTOR
PROGRAMMING
149
Details of the automatic screen ON/OFF state
ID No. State information Description
320 0
1
The automatic screen clear state is OFF
The automatic screen clear state is ON
(*) i seires MODEL A (Edition 11 or later)
i seires MODEL B (Edition 01 or later)
(5) Servo motor load current (Series 16/18)
A load current, digitized by the A/D converter, can be read. The read
data is input as a value between –7282.0 and +7282.0 inclusive.
ID No. Meaning
411
412
413
414
415
416
417
418
1st axis servo motor load current
2nd axis servo motor load current
3rd axis servo motor load current
4th axis servo motor load current
5th axis servo motor load current
6th axis servo motor load current
7th axis servo motor load current
8th axis servo motor load current
Details of read data
The actual load current is calculated as follows:
(AD N)/7282 = Load current (A peak)
AD: Input value (value of #8999)
N:
Motor type N value Motor type N value
4-0S
3-0S
4 5S/3000
10S/3000
80
1-0S 12
20S/3000
2-0S
30S/1200
2-0S
1-0S/3000
30/2000 100
0S
5S
10S
20S/1500
40 20S/3000
30S/3000
40S/2000
130
The load current calculated from the above formula is the value
corresponding to the maximum current for the motor being used. The
calculated load current, therefore, becomes smaller than the
continuous rated current for the motor, as displayed on the servo
adjustment screen.
(6) Diagnosis information
Each of one-byte data, ID Nos. 700, 701, and 712, representing a
number from 0 to 255 indicates diagnosis information.
Example: When bit 3 is 1 (on), 8 is output.
When bit 5 is 1 (on), 32 is output.
When bit 3 and bit 5 are 1 (on), 40 is output.
