SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 369

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
359
NOTE
*
1 : Coolant (initial setting data)
In new process generation, the data set here is automatically set as an initial value in the
item of coolant for each process. If the initial setting of the item of coolant is modified during
editing, the new value is reflected in all processes of the program being edited.
*
2 : Finishing allowances X and Z (initial setting data)
In new process generation, the data set here is automatically set as initial values in the items
of finishing allowances for each process. If the initial setting of an item of allowance is
modified during editing, the new value is reflected in all processes (except C-axis notching)
of the program being edited.
*
3 : System area
This area is used by the system. Macro programs cannot understand any data contained
in this area.
*
4 : Type of machining
1 : Bar machining 2 : Tracing 3 : Residual machining
4 : End facing 5 : Threading 6 : Grooving
7 : Necking 8 : Center drilling 9 : Drilling
10 : Tapping 11 : Single action
13 : Subprogram calling 14 : C-axis center drilling 15 : C-axis drilling
16 : C-axis tapping 17 : C-axis grooving 18 : C-axis notching
19 : C-axis cylindrical machining 20 : Transfer 21 : Auxiliary
22 : M process 23 : End process 24 : Y-axis center drilling
25 : Y-axis drilling 26 : Y-axis tapping 27 : Y-axis milling
*
5 : Machining area (depending on the type of machining)
S <Bar machining/tracing>
1 : Outer surface edge 2 : Outer non-edge surface
3 : Inner surface edge 4 : Inner MID
2 : End face edge 6 : End face non-edge surface
7 : OUT-ENDBK 8 : OUT-MIDBK
9 : INN-ENDBK 10 : INN-MIDBK
11 : FACE-BACK 12 : FACE-MDBK(No.7 to No.12 are available only
for bar machining)
S <Residual machining>
1 : Outer surface 2 : Inner surface 3 : End face
4 : BOTTOM UED
S <Threading>
1 : Outer surface 2 : Inner surface
S <Grooving>
1 : Outer surface 2 : Inner surface 3 : End face
S <Necking>
1 : Outer surface right side 2 : Outer surface left side
3 : Inner surface right side 4 : Inner surface left side
5 : End face upper side 6 : End face lower side
S <C-axis center drilling/C-axis drilling/C-axis tapping/C-axis grooving/C-axis notching/
Y-axis center drilling/Y-axis drilling/Y-axis tapping/Y-axis milling>
1 : End face 2 : Side face
*
6 : Tool post selection (Spindle-axis selection)
1 : Tool post 1 2 : Tool post 2
3 : Both turret, both spindle
