  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 469

Programming manual
B–61803E–1/10
G. DIFFERENCES BETWEEN
Series 0 AND Series 16/18/0i
(CONVERSION FROM FS0 TO FS16/18/0i)
APPENDIX
459
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9002 EVF
#3 (EVF) 0 : Extended P-CODE variables (#20000 or larger) are
floating-point type.
1 : Extended P-CODE variables (#20000 or larger) are integer
type.
(Numeric values –32768 to +32767 can be handled.)
NOTE
When extended P-CODE variables are integer type, note the
following:
1 When an extended P-CODE variable is specified on the left
side of an expression, the result of calculation is rounded off
and assigned.
2 When an extended P-CODE variable is referenced in an
expression, it is converted to floating-point type.
Compile parameter
9037 Number of P–CODE dedicated variables to be used (0 to 60)
Sets the number of P-CODE dedicated variables to be used in units
of 100.
9037 = 12 or less for 20m tape storage
9037 = 25 or less for 40m tape storage
9037 = 51 or less for 80m tape storage
9037 = 60 or less for 160m to 1280m tape storage
G.11
THE USE OF P–CODE
DEDICATED
VARIABLES HAS
BEEN EXTENDED.
