1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 462

Programming manual
F. MACRO VARIABLES USED IN THE
MACRO EXECUTOR FUNCTIONS
B–61803E–1/10
APPENDIX
452
Variable No.
Execut-
able
Auxiliary
Conversa-
tional
R/WFunction
#8731 PMC control command variable (Area C) R/W Ę Ę
#8732 PMC cutting feedrate variable (Area C) R/W Ę Ę
#8733 Variable for traveling distance controlled by PMC (Area C) R/W Ę Ę
#8735 Read variable for PMC status signal (Area C) R Ę Ę
#8740 PMC command signal variable (Area D) R/W Ę Ę
#8741 PMC control command variable (Area D) R/W Ę Ę
#8742 PMC cutting feedrate variable (Area D) R/W Ę Ę
#8743 Variable for traveling distance controlled by PMC (Area D) R/W Ę Ę
#8745 Read variable for PMC status signal (Area D) R Ę Ę
Torque limit control
#8621 Override value of the torque limit for the 1st servo axis R/W Ę Ę Ę
#8622 Override value of the torque limit for the 2nd servo axis R/W Ę Ę Ę
#8623 Override value of the torque limit for the 3rd servo axis R/W Ę Ę Ę
#8624 Override value of the torque limit for the 4th servo axis R/W Ę Ę Ę
#8625 Override value of the torque limit for the 5th servo axis R/W Ę Ę Ę
#8626 Override value of the torque limit for the 6th servo axis R/W Ę Ę Ę
#8627 Override value of the torque limit for the 7th servo axis R/W Ę Ę Ę
#8628 Override value of the torque limit for the 8th servo axis R/W Ę Ę Ę
Reading A/D converter data (Series 16/18)
#8631 A/D converter data for channel 1 R Ę Ę
#8632 A/D converter data for channel 2 R Ę Ę
#8633 A/D converter data for channel 3 R Ę Ę
#8634 A/D converter data for channel 4 R Ę Ę
Window function
#8998 System information ID R/W Ę Ę
#8999 System information R Ę Ę
Reading custom macro variables
#99000 –
#99999
#99000 + Custom macro variable number R/W Ę Ę Ę
Offset memory and wark piece coordinate system (Series 16/18)
#100000 – Extended system variable for the offset memory and workpiece
coordinate system
R/W Ę Ę Ę
R : Readable W : Writable Ę : Usable : Unusable
