B. MACRO COMPLIER OPERATION
(Series 16–A/18–A)
B–61803E–1/10
APPENDIX
240
(Return to) Initial Screen <F0> - <F2> OFF and press ”R2”
NO=
1 <NL>
PROGRAM
= O program No. <NL> (Number to be corrected)
EDIT=
(1) Screen Edit
D
Press the ”CHG” key. (Check that F15 key lights up)
Skip the cursor at the upper left part of the screen, and move it to
the place to be corrected, using the CURSOR key. After
completion of correction, return the ”CHG” key to the lower left
part of the screen again.
”CHG”: Screen edit switching (F15 key ON)
”INS”: Insertion: the line is spaced out by a push on this key
when the cursor is located in Line No.
”DEL”: Deletion: the line is deleted by a push on this key when
the cursor is located in Line No. (Do this most carefully.)
”R1”: Correction/cancellation: the current data is corrected and
canceled on that screen.
The cursor is moved to the upper left part of the screen.
”R2”: Page shift backward
”R3”: Page shift forward
D
After correction, press the ”CHG” key once again. (Check that F15 key
goes off.)
The cursor returns to the lower left part of the screen.
(”EDIT = ” is displayed at the lower part left of the screen.)
(Return to) Initial Screen <F0> - <F2> OFF and press ”R2”
NO=
1 <NL>
PROGRAM
=O Program No. <NL> (Number to be corrected)
EDIT
=
Command Edit
D
Check that left lower part of the screen is ”EDIT = ”.
D Check that the cursor is located at the left lower part of the screen.
D Replacement : Line No. Program one line <NL>
D Insertion : New Line No.
Program one line <NL>
D One-line deletion : Line No. <NL>
D Plural deletion : Start Line No., End Line No. <NL>
D Display : L
Line No. <NL>
D Line renewal : REN <NL>
D Copy : MOVE (Start Line No., End Line No. )
/Frequency <NL>
MOVE
Frequency <NL>
D Substitute : A (Start Line No., End Line No.
)
/Original character string/
New character string /All <NL>
A
/Original character string/,
/New character string/, /All <NL>
B.1.4
Correcting Macro
Program (Screen edit)
B.1.5
Correcting Macro
Program (Command
edit)
Previous page
Next page

Contents Summary of SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual
