SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 270

Programming manual
D. MACRO COMPILER/MACRO
EXECUTOR WITH CAP I (Series 16/18)
B–61803E–1/10
APPENDIX
260
The maximum number of variables that can be set to parameter
No. 9044 varies, as shown below, in accordance with the part
program memory capacity.
Example)
Part program memory 160 m: Parameter No. 9044 = 819
Part program memory 320 m: Parameter No. 9044 = 1638
6. When setting of all necessary parameters is completed, press the
R0 key, then press the <NL> key twice to return to the initial
screen.
(8) Test Compiling
1. Press the R0 key in the initial screen.
2. To display the source program during compiling, put the F3 key
into ON status, and to display only the program number, put the
F3 key into OFF status.
3. Key in ‘1<NL>’ from ’NO.=’.
4. As the dedicated custom macro program for CAP and the user’s
program are compiled simultaneously, check for the absence of
errors.
(9) Setting the FA writer channel
1. Press the R1 key in the initial screen.
2. By keying in ‘2<NL>’ from ’‘NO.=’, the current FA writer
channel setting status is displayed.
3. Concerning CN=1
‘ON<NL>’ :Uses the channel
‘OFF<NL>’ :Does not use the channel
‘<NL>’ :Setting is unchanged
4. The same as above applies to CN=2
5. The same as above applies to CN=3
6. By only pressing ‘<NL>’ in response to ‘NO=’, the display
returns to the initial screen.
(10)Preparation of the FA writer
1. Install a ROM module with the previous contents erased in the
FA writer
2. Switch ON the power supply of the FA writer
3. Set FA writer to the Remote mode.
(11)ROM writing
1. Press the R0 key in the initial screen.
2. Put the F7 into OFF and the F9 key into ON status. (FA writer
selection)
3. When you want to display the source program during compiling,
put the F3 key into ON status, and when you want to display only
the program number, put the F3 key into OFF status.
4. Key in ‘2<NL>’ from ‘NO=’.
5. If the floppy disk containing macro executor 2 is already inserted
in floppy disk drive 0, the data will be read automatically from
the second floppy disk and simultaneously written into the ROM
module. If the floppy disk has not been inserted in the disk drive,
