1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 466

Programming manual
G. DIFFERENCES BETWEEN
Series 0 AND Series 16/18/0i
(CONVERSION FROM FS0 TO FS16/18/0i)
B–61803E–1/10
APPENDIX
456
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9005 TMACC AXCLS AX4CL AX3CL AX2CL AX1CL
AX1CL 0 : Subprogram call by the 1st address is invalid
1 : Subprogram call by the 1st address is valid
AX2CL 0 : Subprogram call by the 2nd address is invalid
1 : Subprogram call by the 2nd address is valid
AX3CL 0 : Subprogram call by the 3rd address is invalid
1 : Subprogram call by the 3rd address is valid
AX4CL 0 : Subprogram call by the 4th address is invalid
1 : Subprogram call by the 4th address is valid
AXCLS 0 : Always program O9009 is called irrespective of specified
axes.
1 : The program number to be called depends on a specified
axis:
Program O9031 is called when 1st axis is specified.
Program O9032 is called when 2nd axis is specified.
::
Program O9038 is called when 8th axis is specified.
TMACC 0 : Macro call by T code is invalid
1 : Macro call by T code is valid
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9008 HRGCC AX8CL AX7CL AX6CL AX5CL
AX5CL 0 : Subprogram call by the 5th axis address is made invalid.
1 : Subprogram call by the 5th axis address is made valid.
AX6CL 0 : Subprogram call by the 6th axis address is made invalid.
1 : Subprogram call by the 6th axis address is made valid.
AX7CL 0 : Subprogram call by the 7th axis address is made invalid.
1 : Subprogram call by the 7th axis address is made valid.
AX8CL 0 : Subprogram call by the 8th axis address is made invalid.
1 : Subprogram call by the 8th axis address is made valid.
HRGCC 0 : Character display screen is not set to the intensity
modulation mode.
1 : Character display screen is set to the intensity modulation
mode.
G.7
CALLING A
SUBPROGRAM WITH
AN AXIS ADDRESS
