PROGRAMMING

B–64124EN/01

13. FUNCTIONS TO SIMPLIFY

PROGRAMMING

185

Specify P and Q in a block that performs drilling. If they are specified in

a block that does not perform drilling, they are not stored as modal data.

When Q0 is specified, the peck rigid tapping cycle is not performed.

Do not specify a group 01 G code (G00 to G03) and G73 in the same block.

If they are specified together, G73 is canceled.

In the canned cycle mode, tool offsets are ignored.

The rigid tapping canned cycle is canceled. For how to cancel this cycle,

see II–13.1.14.

NOTE

When Rigid Tapping Cancel is commanded, the S

command, which is used at rigid tapping, is also cleared. (It

is the same that S0 is commanded.)

Therefore, the S command, which is specified for rigid

tapping, can not be used at blocks after Rigid Tapping

Cancel. Please re–specify S command after Rigid Tapping

Cancel if necessary.

D P/Q

D Cancel

D Tool offset

13.2.4

Canned Cycle Cancel

(G80)
