0i - MC Operators manual Page 390

Operators manual

Page of 918

/ 918

PROGRAMMING

16. PATTERN DATA INPUT

FUNCTION

B–64124EN/01

366

Custom macros for the menu title and hole pattern names.

1. BOLT HOLE

2. GRID

3. LINE ANGLE

4. TAPPING

5. DRILLING

6. BORING

7. POCKET

8. PECK

9. TEST PATRN

10. BACK

MENU : HOLE PATTERN O0000 N00000

> _

MDI **** *** *** 16:05:59

[ MACRO ] [ MENU ] [ OPR ] [ ] [ (OPRT) ]

O9500 ;

N1 G65 H90 P072079 Q076069 R032080 I065084 J084069 K082078 ; HOLE PATTERN

N2 G65 H91 P1 Q066079 R076084 I032072 J079076 K069032 ; 1.BOLT HOLE

N3 G65 H91 P2 Q071082 R073068 ; 2.GRID

N4 G65 H91 P3 Q076073 R078069 I032065 J078071 K076069 ; 3.LINE ANGLE

N5 G65 H91 P4 Q084065 R080080 I073078 J071032 ; 4.TAPPING

N6 G65 H91 P5 Q068082 R073076 I076073 J078071 ; 5.DRILLING

N7 G65 H91 P6 Q066079 R082073 I078071 ; 6.BORING

N8 G65 H91 P7 Q080079 R067075 I069084 ; 7.POCKET

N9 G65 H91 P8 Q080069 R067075 ; 8.PECK

N10 G65 H91 P9 Q084069 R083084 I032080 J065084 K082078 ; 9.TEST PATRN

N11 G65 H91 P10 Q066065 R0670750 ; 10.BACK

N12 M99 ;

Example
