OPERATION11. SETTING AND DISPLAYING DATA
B–64124EN/01
666
Tool offset values, tool length offset values, and cutter compensation
values are specified by D codes or H codes in a program. Compensation
values corresponding to D codes or H codes are displayed or set on the
screen.
Procedure for setting and displaying the tool offset value
1 Press function key
OFFSET
SETTING
.
2 Press chapter selection soft key
[OFFSET] or press
OFFSET
SETTING
several
times until the tool compensation screen is displayed.
OFFSET O0001 N00000
NO. GEOM(H) WEAR(H) GEOM(D) WEAR(D)
001 10.000 0.000 0.000 0.000
002 –1.000 0.000 0.000 0.000
003 0.000 0.000 0.000 0.000
004 20.000 0.000 0.000 0.000
005 0.000 0.000 0.000 0.000
006 0.000 0.000 0.000 0.000
007 0.000 0.000 0.000 0.000
008 0.000 0.000 0.000 0.000
ACTUAL POSITION (RELATIVE)
X 0.000 Y 0.000
Z 0.000
> _
MDI **** *** *** 16:05:59
[ OFFSET ] [ SETING ] [ WORK ] [ ] [ (OPRT) ]
3 Move the cursor to the compensation value to be set or changed using
page keys and cursor keys, or enter the compensation number for the
compensation value to be set or changed and press soft key
[NO.SRH].
4 To set a compensation value, enter a value and press soft key
[INPUT].
To change the compensation value, enter a value to add to the current
value (a negative value to reduce the current value) and press soft key
[+INPUT]. Or, enter a new value and press soft key [INPUT].
A decimal point can be used when entering a compensation value.
An external input/output device can be used to input or output a tool offset
value. See III–8. A tool length offset value can be set by measuring the
tool length as described in the next subsection.
11.4.1
Setting and Displaying
the Tool Offset Value
Procedure
Explanations
D Decimal point input
D Other setting method
