PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–64124EN/01

392

Num-

ber

Message Description

5110 IMPROPER G CODE

(G05.1 Q1 MODE)

An unspecifiable G code was specified in

the AI advanced preview control/AI con-

tour control mode.

5111 IMPROPER MODAL

G CODE

(G05.1 Q1)

An unavailable modal G code was found

when the AI advanced preview control/AI

contour control mode was specified.

5112 G08 CAN NOT BE

COMMANDED

(G05.1 Q1)

The look–ahead control command (G08)

was specified in the AI advanced preview

control/AI contour control mode.

5114 CAN NOT ERROR IN

MDI MODE

(G05.1 Q1)

Intervention by manual operation was per-

formed during execution of the G28, G30,

or G53 command (linear interpolation

type) in the AI advanced preview control/

AI contour control mode. After that, auto-

matic operation was restarted at a position

other than the stop position.

5156 ILLEGAL AXIS

OPERATION

(AICC)

In the AI advanced preview control/AI con-

tour control mode, the controlled axis

selection signal (PMC axis control)

changed.

In the AI advanced preview control/AI con-

tour control mode, the simple synchronous

axis selection signal changed.

5157 PARAMETER 0

(AICC)

The setting of the parameter for specifying

the maximum cutting feedrate (No. 1422,

1432, or 1420) is 0.

The setting of the parameter for specifying

acceleration/deceleration before interpola-

tion (No. 1770 or 1771) is 0.

1) The advanced preview control function (G08P1) can also be specified.

2) When the total distance of blocks read in advance reaches the distance

for decelerating from the current feedrate, deceleration is started.

When look–ahead operation proceeds and the total distance of blocks

increases by termination of deceleration, acceleration is started again.

If a series of blocks with a small amount of travel are specified, the

deceleration and acceleration may be alternated, which prevents the

feedrate from being constant. In this case, specify a lower feedrate.

3) When the dry run signal is inverted from ”0” to ”1” or from ”1” to ”0”

during movement along an axis, acceleration/deceleration is

performed to the specified feedrate without deceleration to feedrate 0.

4) If a non–movement block or one–shot G code command such as G04

is found in the AI advanced preview control/AI contour control mode,

the movement is decelerated and temporarily stopped in the preceding

block.

5) For acceleration/deceleration after interpolation, use linear or

bell–shaped acceleration/deceleration. Exponential acceleration/

deceleration cannot be used.

Alarms

Notes
