19. HIGH SPEED CUTTING

FUNCTIONS

401

the acceleration/deceleration reference speed is set in parameter No.

7066.

Because these parameters must be set in input unit, when the input unit

is changed, these parameters must be changed.

This method is used if the G05.1Q1 block does not have an F command.

The speed specified with the F command issued when a cutting block

group (such as G01 and G02) starts is assumed the

acceleration/deceleration reference speed,

This method is used if the G05.1Q1 block does not have an F command

and the parameter of the acceleration/deceleration reference speed is set

to 0.

(G00)

G01 X––– Y––– Z––– F*** ;

X––– Y––– Z–––

G00 ;

Cutting block group

Even if an F command is issued before a cutting block group and the F

command is effective to the cutting block group modally, the speed

specified with the modal F effective at the start of cutting will be assumed

the acceleration/deceleration reference speed.

Optimum bell–shaped acceleration/deceleration before interpolation, as

mentioned here, refers to bell–shaped acceleration/deceleration before

interpolation in which linear acceleration/deceleration not reaching the

specified acceleration/deceleration does not occur if T2 > T1. Calculation

is performed as described below.

(1) If the bell–shaped acceleration/deceleration before interpolation time

constant T2’ is calculated under the condition that the bell–shaped

acceleration/deceleration before interpolation must not have a linear

portion,

F2T

’

T2: Acceleration change time specified for bell–shaped acceleration/

deceleration before interpolation

F: Acceleration/deceleration reference speed

A: Acceleration for the acceleration/deceleration before interpolation

(2) Setting the speed on

the Parameter

(3) Using the speed

specified with the F

command issued at

the start of cutting as

the reference speed

D Acceleration/deceleratio

n parameter calculation

method
