PROGRAMMING

B–64124EN/01

15. CUSTOM MACRO

313

NOTE

Do not substitute a negative value.

Modal information specified in blocks up to the immediately preceding

block can be read.

Table 15.2 (h) System variables for modal information

Variable number

Function

#4001

#4002

#4003

#4004

#4005

#4006

#4007

#4008

#4009

#4010

#4011

#4012

#4013

#4014

#4015

#4016

#4022

#4102

#4107

#4109

#4111

#4113

#4114

#4115

#4119

#4120

#4130

G00, G01, G02, G03, G33, G75, G77,

G78, G79 (Group 01)

G17, G18, G19 (Group 02)

G90, G91 (Group 03)

G22, G23 (Group 04)

G94, G95 (Group 05)

G20, G21 (Group 06)

G40, G41, G42 (Group 07)

G43, G44, G49 (Group 08)

G73, G74, G76, G80–G89 (Group 09)

G98, G99 (Group 10)

G50, G51 (Group 11)

G66, G67 (Group 12)

G96,G97 (Group 13)

G54–G59 (Group 14)

G61–G64 (Group 15)

G68, G69 (Group 16)

: :

G50.1, G51.1 (Group 22)

B code

D code

F code

H code

M code

Sequence number

Program number

S code

T code

P code (number of the currently selected addition-

al workpiece coordinate system)

Example:

When #1=#4002; is executed, the resulting value in #1 is 17, 18, or 19.

If the specified system variable for reading modal information

corresponds to a G code group which cannot be used, a P/S alarm is

issued.

D Modal information
