PROGRAMMING
B–64124EN/01
19. HIGH SPEED CUTTING
FUNCTIONS
397
When G05.1 Q1 is specified, the modal G codes must be set as listed
below. If one of these conditions is satisfied, a PS5111 alarm occurs.
G code(s) Description
G00
G01
G02
G03
Positioning
Linear interpolation
Circular interpolation (CW)
Circular interpolation (CCW)
G15 Polar coordinate command cancel
G40 Cutter compensation cancel
G40.1 Normal direction control cancel mode
G49 Tool length compensation cancel
G50 Scaling cancel
G50.1 Programmable mirror image cancel
G64 Cutting mode
G67 Macro modal call cancel
G69 Coordinate system rotation cancel
G80 Canned cycle cancel
G94 Feed per minute
G97 Constant surface speed control cancel
G160 In–feed control function cancel
D Conditions for setting the
AI advanced preview
control/AI contour
control mode
