15. CUSTOM MACRO

325

The sample program below finds the total of numbers 1 to 10.

O9500;

#1=0; Initial value of the variable to hold the sum. . . . . . . . . . . . . . . . . . .

#2=1; Initial value of the variable as an addend. . . . . . . . . . . . . . . . . . .

N1 IF[#2 GT 10] GOTO 2; Branch to N2 when the addend is greater . .

than 10

#1=#1+#2; Calculation to find the sum. . . . . . . . . . . . . . .

#2=#2+1; Next addend. . . . . . . . . . . . . . . .

GOTO 1; Branch to N1. . . . . . . . . . . . . . . .

N2 M30; End of program. . . . . . . . . . . . . . . . . . .

Specify a conditional expression after WHILE. While the specified

condition is satisfied, the program from DO to END is executed. If the

specified condition is not satisfied, program execution proceeds to the

block after END.

WHILE [conditional expression] DO m ; (m=1,2,3)

END m ;

Processing

If the condi-

tion is not sa-

tisfied

If the condi-

tion is satis-

fied

While the specified condition is satisfied, the program from DO to END

after WHILE is executed. If the specified condition is not satisfied,

program execution proceeds to the block after END. The same format as

for the IF statement applies. A number after DO and a number after END

are identification numbers for specifying the range of execution. The

numbers 1, 2, and 3 can be used. When a number other than 1, 2, and 3

is used, P/S alarm No. 126 occurs.

Sample program

15.5.3

Repetition

(While Statement)

Explanations
