Press function key
POS
to display the current position of the tool.
The following three screens are used to display the current position of the
tool:
⋅Position display screen for the work coordinate system.
⋅Position display screen for the relative coordinate system.
⋅Overall position display screen.
The above screens can also display the feedrate, run time, and the number
of parts. In addition, a floating reference position can be set on these
screens.
Function key
POS
can also be used to display the load on the servo motor
and spindle motor and the rotation speed of the spindle motor (operating
monitor display).
Function key
POS
can also be used to display the screen for displaying
the distance moved by handle interruption. See III– 4.8 for details on this
screen.
11.1
SCREENS
DISPLAYED BY
FUNCTION KEY
<POS>
POS
