APPENDIX

B–64124EN/01

G. ALARM LIST

875

No. DescriptionFaulty location and remedy

SPM

indica-

tion(*1)

Message

9084 SPN_n_ : SPNDL SEN-

SOR DISCON-

NECTED

84 1 Replace the feedback cable.

2 Check the shield processing.

3 Check and correct the connection.

4 Check and correct the parameter.

5 Adjust the sensor.

The spindle sensor feedback signal

is not present.

9085 SPN_n_ : 1–ROT SPNDL

SENSOR ER-

ROR

85 1 Check and correct the parameter.

2 Replace the feedback cable.

3 Adjust the sensor.

The one–rotation signal of the

spindle sensor cannot be correctly

detected.

9086 SPN_n_ : NO 1–ROT

SPNDL SEN-

SOR ERROR

86 1 Replace the feedback cable.

2 Adjust the sensor.

The one–rotation signal of the

spindle sensor cannot be correctly

detected.

9087 SPN_n_ : SPNDL SEN-

SOR SIGNAL

ERROR

87 The one–rotation signal of the

spindle sensor is not generated.

An irregularity was detected in a

spindle sensor feedback signal.

9088 SPN_n_ : COOLING RA-

DIFAN FAIL-

URE

88 Replace the SPM external cooling

fan.

The external cooling fan stopped.

9111 b1 Replace the SVPM control printed

circuit board.

The voltage of the converter control

power supply is low.

9120 C0 1 Replace the communication

cables between the CNC and

SPM.

2 Replace the SPM control printed

circuit board.

3 Replace the spindle interface

printed circuit board in the CNC.

Communication data alarm

9121 C1 1 Replace the communication

cables between the CNC and

SPM.

2 Replace the SPM control printed

circuit board.

3 Replace the spindle interface

printed circuit board in the CNC.

Communication data alarm

9122 C2 1 Replace the communication

cables between the CNC and

SPM.

2 Replace the SPM control printed

circuit board.

3 Replace the spindle interface

printed circuit board in the CNC.

Communication data alarm
