APPENDIXC. RANGE OF COMMAND VALUE
B–64124EN/01
834
Increment system
IS–B IS–C
Least input increment 0.0001 inch 0.00001 inch
Least command increment 0.0001 inch 0.00001 inch
Max. programmable dimension ±9999.9999 inch ±9999.9999 inch
Max. rapid traverse Note 9600 inch/min 4000 inch/min
Feedrate range Note 0.01 to 9600
inch/min
0.01 to 4000
inch/min
Incremental feed 0.0001, 0.001, 0.01,
0.1 inch/step
0.00001, 0.0001,
0.001, 0.01 inch/step
Tool compensation 0 to ±99.9999 inch 0 to ±99.9999 inch
Dwell time 0 to 99999.999 sec 0 to 9999.9999 sec
Increment system
IS–B IS–C
Least input increment 0.001 mm 0.0001 mm
Least command increment 0.0001 inch 0.00001 inch
Max. programmable dimension ±99999.999 mm ±9999.9999 mm
Max. rapid traverse Note 9600 inch/min 4000 inch/min
Feedrate range Note 1 to 240000 mm/min 1 to 100000 mm/min
Incremental feed 0.001, 0.01, 0.1, 1
mm/step
0.0001, 0.001, 0.01,
0.1 mm/step
Tool compensation 0 to ±999.999 mm 0 to ±999.9999 mm
Dwell time 0 to 99999.999 sec 0 to 9999.9999 sec
D In case of inch input,
feed screw is inch
D In case of millimeter
input, feed screw is inch
