APPENDIXG. ALARM LIST

B–64124EN/01

870

No. DescriptionFaulty location and remedy

SPM

indica-

tion(*1)

Message

7n84 SPN_n_ : SPNDL SEN-

SOR DISCON-

NECTED

84 1 Replace the feedback cable.

2 Check the shield processing.

3 Check and correct the connection.

4 Check and correct the parameter.

5 Adjust the sensor.

The spindle sensor feedback signal

is not present.

7n85 SPN_n_ : 1–ROT SPNDL

SENSOR ER-

ROR

85 1 Check and correct the parameter.

2 Replace the feedback cable.

3 Adjust the sensor.

The one–rotation signal of the

spindle sensor cannot be correctly

detected.

7n86 SPN_n_ : NO 1–ROT

SPNDL SEN-

SOR ERROR

86 1 Replace the feedback cable.

2 Adjust the sensor.

The one–rotation signal of the

spindle sensor is not generated.

7n87 SPN_n_ : SPNDL SEN-

SOR SIGNAL

ERROR

87 The one–rotation signal of the

spindle sensor is not generated.

An irregularity was detected in a

spindle sensor feedback signal.

7n88 SPN_n_ : COOLING RA-

DIFAN FAIL-

URE

88 Replace the SPM external cooling

fan.

The external cooling fan stopped.

7n89 89 1 Check the connection in the SPM

and sub–module SM.

2 Replace the sub–module SM.

3 Replace the SPM control printed

circuit board.

The sub–module SM is abnormal.

7n97 SPN_n_ : OTHER

SPINDLE

ALARM

97 Replace the SPM. Another irregularity was detected.

7n98 SPN_n_ : OTHER CON-

VERTER

ALARM

98 Check the PSM alarm display. A PSM alarm was detected.

No. Message

SPM

indica-

tion(*1)

Faulty location and remedy Description

9001 SPN_n_ : MOTOR

OVERHEAT

01 1 Check and correct the peripheral

temperature and load status.

2 If the cooling fan stops, replace it.

The internal temperature of the motor

exceeds the specified level.

The motor is used in excess of the

continuous rating, or the cooling

component is abnormal.

9002 SPN_n_ : EX SPEED ER-

ROR

02 1 Check and correct the cutting

conditions to decrease the load.

2 Correct parameter No. 4082.

The motor speed cannot follow a spe-

cified speed.

An excessive motor load torque is de-

tected.

The acceleration/deceleration time in

parameter No. 4082 is insufficient.
