QuickTurn Electronic Lathe Version 0i_V1_10 Operators manual Page 46

Operators manual
QuickTurn™
GE Fanuc Automation S.A. Page 45 GFKE-0047C-EN
Number Alarm Details
033 NO SOLUTION AT NRC A point of intersection cannot be determined for tool nose
radius compensation. Modify the program.
035 CAN NOT COMMANDED G31 Skip cutting (G31) was specified in tool nose radius
compensation mode. Modify the program.
037 CAN NOT CHANGE PLANE IN
NRC
The offset plane is switched in tool nose radius compensation.
Modify the program.
038 INTERFERENCE IN CIRCULAR
BLOCK
Overcutting will occur in tool nose radius compensation
because the arc start point or end point coincides with the arc
center.
Modify the program.
041 INTERFERENCE IN NRC Overcutting will occur in tool nose radius compensation.
Modify the program.
059 PROGRAM NUMBER NOT
FOUND
In an external program number search or external workpiece
number search, a specified program number was not found.
Otherwise, a program specified for searching is being edited in
background processing. Check the program number and
external signal. Or discontinue the background editing.
060 SEQUENCE NUMBER NOT
FOUND
Commanded sequence number was not found in the
sequence number search. Check the sequence number.
070 NO PROGRAM SPACE IN
MEMORY
The memory area is insufficient.
Delete any unnecessary programs, then retry.
071 DATA NOT FOUND The address to be searched was not found. Or the program
with specified program number was not found in program
number search.
Check the data.
072 TOO MANY PROGRAMS The number of programs to be stored exceeded 63. Delete
unnecessary programs and execute program registration
again.
073 PROGRAM NUMBER ALREADY
IN USE
The commanded program number has already been used.
Change the program number or delete unnecessary programs
and execute program registration again.
074 ILLEGAL PROGRAM NUMBER The program number is other than 1 to 9999.
Modify the program number.
075 PROTECT An attempt was made to register a program whose number
was protected.
076 ADDRESS P NOT DEFINED Address P (program number) was not commanded in the
block which includes an M98, G65, or G66 command. Modify
the program.
077 SUB PROGRAM NESTING
ERROR
The subprogram was called in five folds. Modify the program.
078 NUMBER NOT FOUND A program number or a sequence number which was specified
by address P in the block which includes an M98, M99, M65 or
G66 was not found. The sequence number specified by a
GOTO statement was not found. Otherwise, a called program
is being edited in background processing. Correct the
program, or discontinue the background editing.
079 PROGRAM VERIFY ERROR In memory or program collation, a program in memory does
not agree with that read from an external I/O device. Check
both the programs in memory and those from the external
device.
085 COMMUNICATION ERROR When entering data in the memory by using Reader / Puncher
interface, an overrun, parity or framing error was generated.
The number of bits of input data or setting of baud rate or
specification No. of I/O unit is incorrect.
