QuickTurn Electronic Lathe Version 0i_V1_10 Operators manual Page 48

Operators manual
QuickTurn™
GE Fanuc Automation S.A. Page 47 GFKE-0047C-EN
Number Alarm Details
128 ILLEGAL MACRO SEQUENCE
NUMBER
The sequence number specified in the branch command was
not 0 to 9999. Or, it cannot be searched. Modify the program.
129 ILLEGAL ARGUMENT
ADDRESS
An address which is not allowed in <Argument Designation >
is used.
Modify the program.
224 RETURN TO REFERENCE
POINT
Not returned to reference point before cycle start.
231 FORMAT ERROR IN G10 OR
L50
Any of the following errors occurred in the specified format at
the programmable-parameter input.
1 Address N or R was not entered.
2 A number not specified for a parameter was entered.
3 The axis number was too large.
4 An axis number was not specified in the axis-type
parameter.
5 An axis number was specified in the parameter which is not
an axis type.
6 An attempt was made to reset bit 4 of parameter 3202
(NE9) or change parameter 3210 (PSSWD) when they are
protected by a password. Correct the program.
233 DEVICE BUSY When an attempt was made to use a unit such as that
connected via the RS-232-C interface, other users were using
it.
239 BP/S ALARM While punching was being performed with the function for
controlling external I/O units ,background editing was
performed.
240 BP/S ALARM Background editing was performed during MDI operation.
245 T-CODE NOT ALOWED IN THIS
BLOCK
One of the G codes, G50, G10, and G04, which cannot be
specified in the same block as a T code, was specified with a
T code.
5010 END OF RECORD The end of record (%) was specified.
Background edit alarm
Number Alarm Details
070 to
074
085 to
087
BP/S alarm BP/S alarm occurs in the same number as the P/S alarm that
occurs in ordinary program edit.
140 BP/S alarm It was attempted to select or delete in the background a
program being selected in the foreground. (NOTE)
Use background editing correctly.
Serial pulse coder (SPC) alarms
When either of the following alarms is issued, a possible cause is a faulty serial pulse coder or cable.
Number Alarm Details
350 SPC ALARM: n AXIS PULSE
CODER
The n axis (axis 1-2) pulse coder has a fault. Refer to
diagnosis display No. 202 for details.
351 SPC ALARM: n AXIS
COMMUNICATION
n axis (axis 1-2) serial pulse coder communication error (data
transmission fault)
Refer to diagnosis display No. 203 for details.
