POWER MATE MODEL D/F Maintenance manual Page 124

Maintenance manual

Page of 420

/ 420

B–62835EN/01

2. HARDWARE

113

NAME

D F

Specification

Remarks

NAME

B001 B520 B501 B531 B501 B531

Specification

Remarks

PMC controled module A f f f f A20B–2900–0142 PMC–PA1

PMC controled module B

f f f f A20B–2901–0660 PMC–PA3

f f f f A20B–2901–0662 PMC–PA3

Memory module A

f f A20B–2900–0531 RAM 128KB

f f A20B–2902–0332 RAM 128KB

Memory module B

f f A20B–2900–0530 RAM 256KB

f f A20B–2902–0331 RAM 256KB

Memory module C

f f A20B–2900–0541 RAM 512KB

f f A20B–2902–0330 RAM 512KB

CPU module f f A20B–2901–0500

CRT controled module f f f f A20B–2901–0480

Touch panel connection

module

f f A20B–2902–0470 Touch panel connection

HSSB module f f A20B–2902–0540 HSSB function

Spindle module

f f A20B–2900–0851 Analog spindle

f f A20B–2900–0850 Serial spindle

f f A20B–2901–0210 Analog input\Serial spindle

Digital servo module

f A20B–2900–0160 Corresponding to S series

servo

f A20B–2901–0340 Corresponding to E, α se-

ries servo

Digital servo interface mod-

ule

f f A20B–2900–0380

Memory module CSA f f A20B–2902–0230 RAM addition 512KB

Analog spindlex2

Memory module BSA f f A20B–2902–0231 RAM addition 256KB

Analog spindlex2

Memory module ASA f f A20B–2902–0232 Analog spindlex2

Memory module BSA f f A20B–2902–0234 RAM addition 256KB

Analog spindle

Memory module ASA

Spindle module S analog

f f f f A20B–2902–0235 Analog spindle

Memory module C f f A20B–2902–0236 RAM addition 512KB

Memory module B f f A20B–2902–0237 RAM addition 256KB

Memory module BSSA f A20B–2902–0221 RAM addition 256KB

Serial spindle

Analog input

Memory module ASSA f f A20B–2902–0222 Serial spindle

Analog input

Memory module CSS f f A20B–2902–0223 RAM addition 512KB

Serial spindle

Memory module BSS f f A20B–2902–0224 RAM addition 256KB

Serial spindle

Memory module ASS

Spindle module S serial

f f f f A20B–2902–0225 Serial spindle
